AIR ACTUATED DOUBLEDISC VALVE
|
PARTS |
1C |
Body |
|
2C |
Piston Rack |
(2) |
3C |
End Cap |
(2) |
4C |
Gear |
|
5C |
End Cap "O" Ring |
(2) |
6C |
Piston Seal |
(2) |
7C |
"O" Ring |
(2) |
8C |
Gear Shaft "O" Ring |
(2) |
9C |
Top Cap |
|
10C |
Adaptor |
|
11C |
Brass Coupling |
|
12C |
Top Cap Bolt |
(2) |
13AC |
Adaptor Bolt |
(2) |
13BC |
Set Screw for Clamp Adaptor |
|
15C |
Spring Unit |
(2) |
|
Dimensions in mm. LUDD7 with actuator |
|
2" |
2 1/2" |
3" |
A |
47 |
57 |
64 |
B |
47 |
57 |
64 |
|
77 |
87 |
94 |
71 |
81 |
88 |
D |
80 |
100 |
105 |
E |
174 |
214 |
233 |
G |
248 |
281 |
320 |
H |
153 |
158 |
180 |
AIR -TO- AIR |
|
AIR PRESSURE REQUIREMENTS: Use lubricated air |
Actuator Air-to-Open, Air-to-Close..............................75 to 120 psi |
|
ACTUATOR DIMENSIONS - mm |
AIR -TO- AIR |
SIZE |
AA 50 |
AA 60 |
AA 70 |
AA 80 |
D |
74 |
74 |
84 |
94 |
L |
172 |
172 |
172 |
172 |
T |
10 |
10 |
10 |
10 |
C |
94 |
94 |
104 |
114 |
G |
1/8" - ISO |
ADJUSTABLE ACTUATOR AIR TO AIR
AIR -TO-SPRING |
|
AIR PRESSURE REQUIREMENTS: Use lubricated air |
Actuator Air-to-Open, Spring-to-Close..................................80 to 120 psi |
Note: To reverse action to Spring-to-Open, Air-to-Close, please specify when ordering. |
|
ACTUATOR DIMENSIONS - mm |
AIR -TO-SPRING |
SIZE |
AS 60 |
AS 70 |
AS 80 |
D |
74 |
84 |
94 |
L |
260 |
330 |
330 |
T |
10 |
10 |
10 |
C |
94 |
104 |
114 |
G |
1/8" - ISO |
ADJUSTABLE ACTUATOR AIR TO SPRING
