SPARE PARTS LIST - Specify Valve Size

  1   Spider Unit

  4   Body "O" rings*

  2   Spring

  5   Clamp

  3   Disc & Stem

  6   Disc "O" ring*

*Available EPDM or viton®

  SIZE:

0.5"

0.75"

 1"

 1.5"

 2"

 2.5"

 3"

 4"

L1 WELD

75

 75

  60

75

75

75

  75

119

L2 CLAMP

87

87

102

117

117

117

117

161

L2 MALE IDF/RJT

NA

NA

102

117

117

117

117

161 RJT
179 IDF

DIAMETER

63

63

63

93

107

133

145

185

WEIGHT

0.57

0.55

0.65

1.05

1.28

1.81

2.05

4.85
